Wall Panel
Specification
Length Range (mm) 1500, 2000, 3000, 4000, 6000
Thickness Range (mm)
50, 75, 100, 125, 150, 175,200
Width (mm) 600
Dry Density 550 to 700 kg / m3
Compressive Strength
≥ 4 N/mm2
Flexural ≥ 1 N/mm2
Tolerance +/- 2 mm (length-wise) +/- 1 mm (height/thickness)
Water Absorption
+/- 120 g/m2 x sec 0.5 (at 10 mins),
Water Permeability +/- 3.655 x 10 – 11 kg/m2sPa
Drying Shrinkage +/- 0.95 mm/m,
Thermal Conductivity
+/- 0.21 W/m.K
Fire Rating 260 mins @ 100 mm (skim 4 mm both sides)
Sound Transmission Class (STC) Acoustics 39 dB @ 100 mm Bare Wall43 dB @ 100 mm Bare Wall Skim 5 mm49 dB @ 100 mm Bare Wall Plastered 15 mm
Anchorage 100 mm Wall, Pull Down – Passed100 mm Wall, Pull Out – Passed100 mm Wall, Heavy Cabinets – Up to 400 kg
Impact & Stiffness 100 mm Wall – Severed Duty Passed
Edge profile Flat Edge, Tongue & Groove
Reinforced
Mesh
